Product Details
NC SeriesTM Features Standard:
- Stainless Steel CFX® Heat Exchangers
- Patented CFX® stainless steel heat exchangers used in all precooler/reheater and chiller assemblies.
- Fully Hermetic Refrigeration Compressor(s)
- Quiet, reliable operation.
- High Efficiency Moisture Separator
- Collects condensate, eliminates moisture reentrainment.
- Timed Electric Condensate Drain
- Fully adjustable with large port that resists clogging.
- Electronic Performance Controller (optional on 75-400)
- Enables performance modification and real-time monitoring of dryer functions.
- Air-Cooled Refrigeration Condenser (75-2,400)
- Condenser is mounted to maximize air flow.
- Water-Cooled Refrigeration Condensers (3,250-19,200)
- Internally mounted condenser in each module makes use of available cooling supply.
- Multiple Electric Disconnects (3,250-19,200)
- Enable isolation of individual modules for service while dryer remains operational.
- Single Point Electric Service Connection
- Minimizes installation cost.
- Closed Frame Construction
- Full powder coated cabinet protects internal components.
- Air Circuit Precooler/Reheater
- Conditions air optimally for compressed air system.
- Environmentally Friendly Refrigerant
- NC SeriesTM and Multi-Module SeriesTM dryers use
- R-404A refrigerant
Specifications
-
Air Dryer Type
Refrigerated
-
CFM
400
-
Hertz
60 HZ
-
Max PSI
300 PSI
-
Phase
3 Phase
-
Product Model
400 NCG
-
Model
400 NCG
-
Voltage
380
-
In/Out Connection
2" MPT
