Product Details
- Required pre-filtration: 1 μm | Recommended post-filtration: .01 μm
- UL / CSA certified control panel
- RX 10 – 200 115V UL/CSA certified
- RX 125 – 450 230V UL/CSA certified
- RX 250 – 550 460V UL/CSA control panel
- NEW intuitive controller
- NEW improved and proprietary heat exchanger
- NEW externally protected micro-channel condenser
- MODBUS ready
- Outlet pressure dew point: Class 4-5 in accordance with ISO 8573-1:2010
- Max. inlet air temperature: 160 °F
- Min. / max. ambient temperature: 34 °F / 120 °F
- Max. inlet pressure: 232 psig
Specifications
-
Cooling
Air Cooled
-
Flow Rate (scfm)
1500
-
In/Out Connection
4" FLG
-
Drain Type
BEKOMAT
-
Hertz
60 HZ
-
Max Inlet Temp. (F)
160
-
Max PSI
232 PSI
-
Phase
3 Phase
-
Model
DRYPOINT® RX
-
Voltage
460
