Product Details
Specifications
- 200PSIG Design Pressure (Models 15-75SCFM); 150PSIG Design Pressure (Models 100SCFM & Larger)
- Schedule 80, A106B Piping
- 3000# A105 Fittings
- Mounted Pre & After Filter Standard
- Interactive Allen Bradley PLC Controller
Standard Equipment
- ASME/CRN Approved Vessels (HOF 75 and larger)
- UL Listed Components, CA, CE Approved
- Selectable Cycles for Dew Point Requirements
- NEMA 4 Electrical Enclosure
- Stainless Steel Liquid Filled Pressure Gauges
- Nickel Plated Full Flow Safety Valves
- Stainless Steel Control Tubing & 316 SS Compression Fittings
- Premium North American Manufactured Desiccant
Optional Equipment
- System Bypass
- Dual Selectable Filters
- High Pressure (to 1000PSIG)
- Low Ambient Outdoor Modifications
- Alternative Voltages
- Ecotronic Demand Control
- Non-Yellow Metal Construction
- NEMA 7 Electrical Rating (Class I, Div I and Class I, Div II)
- Low Dew Points (down to -100˚F)
- Modified Dimensions/Package Layouts for custom installations
Specifications
-
Air Dryer Type
Desiccant
-
Product Model
HOF Series
