Product Details
Standard Features:
- NEMA 1 Electrical Enclosure
- High Performance Switching Valves:
- 90-600 SCFM - Stainless steel angle seat valves
- 800-5,000 SCFM - High performance butterfly valves
- Stainless Steel Purge Valves - Position Indicator
- -400F Dew Point Air Quality
- Solid State Timer
- Downstream Purge
- Illuminated Status Indication
- Blue Moisture Indicator
- Sound Attenuating Mufflers
- Tower Pressure Gauges
- Pressure Relief Valves
- Prominent Purge Pressure Gauge
- High Strength Activated Alumina Desiccant
- ASME Coded Towers
- Removable Stainless Steel Diffuser Screens
- Accessible Fill and Drain Ports
Specifications
-
Air Dryer Type
Desiccant
-
CFM
1200
-
Hertz
60 HZ
-
Max Inlet Temp. (F)
100
-
Max PSI
100 PSI
-
Phase
1 Phase
-
Product Model
1200ZPB
-
Model
1200ZPB
-
Voltage
115
-
In/Out Connection
3" FPT
